4801-1200 System 2001 Power Curtain Controller
26
Part No. Description
3010-2139 FUSE 10 AMP ¼”X1-1/4” fast acting
3010-2291 FUSE 2 AMP ¼”X1-1/4” fast acting
3010-2527 FUSE 2 AMP 5mmX20mm fast acting
1042-2693 FUSE_HOLDER shock safe
4801-1200 MANUAL S2-OSC-E8
1001-2158 NUT lock 1/2" conduit/panel connector
0406-2602 PLASTIC plug liquid tight connector (controllers)
1004-3356 SCREW machine 10-32X1/2" pan slot stainless
1028-0101 SEAL O-RING retainer for screws on enclosures
3006-2984 WIRE_CONNECTOR 2 pin mini jumper
1013-2047 CABLE_FITTING liquid tight ½
”
3008-0052 TRANSFORMER 120/240Vpri 12/24V sec 40va n/fuse
6407-3032 MOV 120V/240V assy PowerPac
6407-3033 MOV 25V assy PowerPac
6407-2593 Temperature sensor assembly with 10’ cable
6407-3028 Temperature sensor assembly with 25’ cable
1902-0108 CABLE_ASSEMBLY S2-OSC/ACT12 power (4 conductor)
1902-0109 CABLE_ASSEMBLY S2-OSC/ACT12 ribbon(40 conductor)
14. Troubleshooting guide
14.1 If curtain machine does not operate manually…
1. Make sure that the PVR-H is getting voltage. Put meter leads across the AC input labeled BLACK
and WHITE. This should read 110vac or 240VAC depending on model.
2. Check fuse at PVR-H. Fuse should be a 10 Amp.
3. Check curtain machine and make sure that the cam block is not on the limit switches.
4. Check fuse on the circuit board inside the controller (F1) and make sure that you are reading 12VDC
on both sides of this fuse. Fuse should be a 2 amp mini fuse. Note the black lead of your volt meter
should be on the terminal labeled SENSOR,BLACK\SHEILD whenever measuring DC voltages.
5. Checking at the System 2001™ board on Unit 1 or Unit 2, the RED should always have 12 volts DC.
If you read 12VDC at this terminal, check the terminal labeled WHITE. When the manual button is
off you should have 12VDC. When the manual button is in the 'open' or 'close' position, you should
read less then 2.5VDC. Now check the terminal labeled BLACK. When the manual button is in open
you should have 12VDC on the terminal labeled BLACK. When the manual button is in the closed
position you should have less then 2.5VDC.
6. If voltages are not correct you need to check and make sure that the 3 conductor cable that connects
from controller to PVR-H does not have a short. Disconnect power from the System-2001™ and
PVR-H. Then disconnect 3 conductor cable from the PVR-H and System 2001™ making sure that the
ends of the wires are not touching each other and then measure for a short.
7. Disconnect power from PVR-H and remove 9-conductor cable and check the PowerTrak unit. Refer to
the PowerTrak manual for trouble shooting.
14.2 If curtain machine does not operate automatically…
8. Check to see if the unit will operate manually, if not repeat steps 1-7.
9. Check your program settings to make sure they are correct.
10. Check to make sure that your sensor readings are correct.
