4801-1200 System 2001 Power Curtain Controller
19
10.3 Hiding Features
The controller will allow you to "hide" selected features at will. When a feature is hidden, the feature
will continue to operate, but it will not show up when scrolling through the features with the select
feature arrow keys. In a sense, it is like locking individual features. Any feature can be hidden or
shown again. We recommend hiding features that will not change from day to day, such as ratios,
timer period, timer setup, etc., because this will prevent accidental alteration of system settings.
To hide features, press Select Feature up, then press Outside Temp. This will put you into hide
features mode. The top line of the display will show the name of the feature, and the bottom line will
say "Hide this Feature NO". Use the Change Setting up arrow to answer yes, then press Select
Feature to move to the next feature. Go through all the features answering yes or no, until you have
selected all the features you wish to hide. then press Outside Temp again to leave hide features mode.
Now scroll through the features using the Select Features up or down arrow keys to make sure you
have hidden all features you desire. When finished, press Target Temperature Up to return to
Automatic Mode.
11. Maintenance
There are few items on the System 2001™ which require maintenance. This does not mean that maintenance
is not important. Check the calibration of your sensors at least once every two months, and make sure that the
controller is closed tightly to prevent dust buildup inside the enclosure.
12. Wiring Diagrams, Schematics, etc.
Recommended Wire Gauge for LOW VOLTAGE hookup.
Component HHI Wiring Part No. Recommended Wire
Sensor 1502-2427 18/2 Shielded Cable
Hall Effect Devices 1502-2427 18/2 Shielded Cable
PVR-H 1503-1508 18/3 Cable SJT
