Install drip rails, Side view – Hired-Hand Mega-Cool rev 4-08 User Manual
Page 14

Part No. 4801-5093 Rev 4-08
Unitized System
Page 14
Install Drip Rails
1.
Place drip rails along the cut in the pipe as shown at left.
2.
Lay drip rails end to end along the entire length of the pads.
Drip Rail
Pipe
Insert Drip Rail Into Pipe
Side View
Front View
* Wood-Framed Agriculture Example Shown
Flashing
Pipe
Screw
(Attach on 5’
Centers)
Secure Flashing
and Insert Drip
Rail Into Pipe)
Drip Rail
