Watlow Addendum to EZwarePlus User Manual
Page 34

3) Click Exit to close the
Data Transfer (Time-
based) Object window.
(043)
To set up data sampling to log the data:
1) On the Objects menu,
click Data Logging
then choose Data
Sampling.
2) Click New…
(044)
3) In Comment type a
description for the set
of data such as “Loop
1”.
4) For Sampling mode
choose Time-based.
5) For Sampling time
interval choose the
time between samples.
6) For Read address
PLC name choose the
OIT (“Local HMI” by
default).
7) For Read address
device type choose
LW.
(045)
Silver Series EM OIT
34
Watlow Addendum
