Watlow Addendum to EZwarePlus - Manual (Page 14)

14) To set up communications with controllers connected to other COM ports or to configure
additional controllers communicating via Ethernet:
• Click New...
• Repeat from step 7 above.
15) Click OK to close the System Parameter Settings dialog.
16) Save the project:
• From the File menu, choose Save.
• In File name type First Project.emtp.
• Click Save.
Create a Popup Window
This example assumes you have created a project that is configured to communicate with a Watlow
controller and that project is open in EZwarePlus.
1) From the Window
menu, choose Open
Window.
2) Click New…
(006)
3) Click Base Window.
(007)
Silver Series EM OIT  14  Watlow Addendum
