ECW-281B-D2550 Embedded System
Page 83
6.2.7 Fan Connectors (CPU_FAN1, SYS_FAN1)
6.2.8 Keyboard/Mouse Connector (KB_MS1)
6.2.9 LVDS1 Connector (LVDS1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 GND
3 LVDS_DATA0 4 LVDS_DATA0#
5 LVDS_DATA1 6 LVDS_DATA1#
7 LVDS_DATA2 8 LVDS_DATA2#
9 LVDS_CLK 10 LVDS_CLK#
11 LVDS_DATA3 12 LVDS_DATA3#
13 GND 14 GND
15 LDDC_DATA 16 LDDC_CLK
17 VCC_LCD 18 VCC_LCD
19 VCC_LCD 20 VCC_LCD
Table 6-10: LVDS1 Connector (LVDS1) Pinouts
PIN NO. DESCRIPTION
1 GND
2 +12 V
3 Fan Speed Detect
Table 6-8: Fan Connector (CPU_FAN1, SYS_FAN1) Pinouts
PIN NO. DESCRIPTION
1 +5 V KB DATA
2 MS DATA
3 MS CLK
3 KB DATA
5 KB CLK
6 GROUND
Table 6-9: Keyboard/Mouse Connector (KB_MS1) Pinouts
