6.2 Internal Peripheral Connectors
Internal peripheral connectors are found on the motherboard and are only accessible
when the motherboard is outside of the chassis. The table below shows a list of the
peripheral interface connectors on the ECW-281B-D2550 motherboard. Pinouts of these
connectors can be found in the following sections.
Connector Type Label
5 V SATA power connectors 2-pin wafer SATA_PWR1,
SATA_PWR2
12 V power connector 4-pin Molex power
connector
CN3
Audio connector 10-pin box header AUDIO1
Backlight inverter connectors 5-pin wafer INV1, INV2
Battery connector 2-pin wafer CN1
Digital Input/Output (DIO) connector 10-pin header DIO1
Fan connectors 3-pin wafer CPU_FAN1,
SYS_FAN2
Keyboard and mouse connector 6-pin wafer KB_MS1
LVDS connectors 20-pin/30-pin crimp LVDS1, LVDS2
PCIe Mini card slots 52-pin PCIe Mini M_PCIE1, M_PCIE2
Power & HDD LED connector 6-pin header CN2
Power button connector 2-pin wafer PWR_BTN1
Reset button connector 2-pin wafer RST_BTN1
RS-232 serial port connectors 10-pin header COM2, COM3
RS-422/485 serial port connector 4-pin wafer COM4
Serial ATA (SATA) drive connectors 7-pin SATA SATA1, SATA2
USB 2.0 connectors 8-pin header USB2, USB3
Table 6-1: Peripheral Interface Connectors
