ECW-281B-D2550 Embedded System
Page 30
3.7.3 Mounting the System with DIN Rail Mounting Kit
To mount the ECW-281B-D2550 embedded system onto a DIN rail, please follow the
steps below.
Step 1: Attach the DIN rail mounting bracket to the bottom panel of the embedded
system. Secure the bracket to the embedded system with the supplied retention
screws (Figure 3-19).
Figure 3-19: DIN Rail Mounting Bracket
Step 2: Make sure the inserted screw in the center of the bracket is at the lowest
position of the elongated hole (
765
Figure 3-20 ).
Figure 3-20: Screw Locations
