ECW-281B-D2550 Embedded System
Page 29
Step 8: Carefully insert the screws through the holes and gently pull the monitor
downwards until the ECW-281B-D2550 rests securely in the slotted holes
(
765
Figure 3-18 ). Ensure that all four of the mounting screws fit snuggly into their
respective slotted holes.
NOTE:
In the diagram below the bracket is already installed on the wall.
Figure 3-18: Mount the Embedded System
