ECW-281B-D2550 Embedded System
Page 6
1.5 Internal Overview
The ECW-281B-D2550 internal components are listed below:
1 x Motherboard
1 x DDR3 SO-DIMM
1 x Power module (WD models only)
1 x Hard drive bracket (attached on the inside of the bottom panel)
All the components are accessed by removing the bottom surface.
Figure 1-5: Internal Overview
1.6 Technical Specifications
The ECW-281B-D2550 technical specifications are listed in Table 1-2.
Specifications
System
Motherboard Model
WAFER-CV-D25501
CPU
1.86 GHz Intel® Atom™ D2550 dual-core processor
Chipset Intel® NM10
Memory Preinstalled 2 GB 204-pin DDR3 SO-DIMM
Ethernet Dual Realtek RTL8111E PCIe GbE controller
Wireless (Wireless
Models Only)
802.11b/g/n 2T2R wireless module
