ECW-281B-D2550 Embedded System
Page 65
5.3.7 F81866 H/W Monitor
The F81866 H/W Monitor menu (BIOS Menu 10) contains the fan configuration
submenus and displays operating temperature, fan speed and system voltages.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
PC Health Status
> Smart Fan Mode Configuration
System Temperature : +49 C
CPU_FAN1 Speed : N/A
+VCC_CPU : +1.200 V
+VCC_GFX : +0.968 V
+V1.05S : +1.056 V
+V1.5_DDR3 : +1.520 V
VSB5V : +5.088 V
+V3.3S : +3.312 V
VSB3V : +3.344 V
VBAT : +3.248 V
Smart Fan Mode Select
---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 10: H/W Monitor
PC Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
System Temperature
CPU Fan Speed
Voltages:
o +VCC_CPU
o +VCC_GFX
o +V1.05S
o +1.5_DDR3
o VSB5V
o +V3.3S
o VSB3V
o VBAT
