IEI Integration NOVA-945GSE v1.01 User Manual
Page 84
NOVA-945GSE 5.25” SBC
Page 84
Figure 4-26: RJ-45 Ethernet Connector
The RJ-45 Ethernet connector has two status LEDs, one green and one yellow. The green
LED indicates activity on the port and the yellow LED indicates the port is linked. See
810H775H
Table 4-26.
STATUS
DESCRIPTION
STATUS
DESCRIPTION
GREEN Activity
YELLOW
Linked
Table 4-26: RJ-45 Ethernet Connector LEDs
