NOVA-945GSE 5.25” SBC
Page 75
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GROUND 25 GROUND
2 SDVOC_CLK- 26 SDVOB_BLUE-
3 SDVOC_CLK+ 27 SDVOB_BLUE+
4 GROUND 28 GROUND
5 SDVOC_GREEN- 29 SDVOB_RED-
6 SDVOC_GREEN+ 30 SDVOB_RED+
7 GROUND 31 GROUND
8 SDVOB_CLK- 32 SDVO1_STALL-
9 SDVOB_ CLK+ 33 SDVO1_STALL+
10 GROUND 34 GROUND
11 SDVOB_GREEN- 35 SDVO_TVCLKIN-
12 SDVOB_GREEN+ 36 SDVO_TVCLKIN+
13 GROUND 37 GROUND
14 SDVOC_INT+ 38 SDVO_CLK
15 SDVOC_INT+ 39 SDVO_DATA
16 GROUND 40 PCIRST
17 SDVOB_INT+ 41 +5VS
18 SDVOB_INT+ 42 +5VS
19 GROUND 43 +5VS
20 SDVOC_BLUE- 44 NC
21 SDVOC_BLUE+ 45 NC
22 GROUND 46 GROUND
23 SDVOC_RED- 47 GROUND
24 SDVOC_RED+
Table 4-17: SDVO Connector Pinouts
