NOVA-945GSE 5.25” SBC
Page 24
Memory
One 200-pin SO-DIMM socket supports one 533/400 MHz
2.0 GB (max.) DDR2 SDRAM SO-DIMM
CompactFlash® One CompactFlash® Type II socket
Super I/O ITE IT8718F
Display
Analog CRT supports CRT hot-plug
HDTV with 1080i maximum resolution supported
18-bit dual-channel LVDS integrated in Intel® 945GSE
BIOS AMI BIOS label
Audio Realtek ALC655 AC'97 codec
LAN Two Realtek RTL8111CP GbE controllers
COM
Three RS-232 serial ports
One RS-232/422/485 serial port
USB2.0 Six USB 2.0 devices supported by on-board pin-headers
SATA Two 1.5 Gbps SATA drives supported
Keyboard/mouse One 6-pin header for keyboard and mouse
Parallel Port One 26-pin parallel port connector
Hard Drives
One 44-pin IDE connector connects to two Ultra ATA33/66/100
devices
TPM One 20-pin header support TPM function
Expansion
One PC/104-Plus expansion slot (ISA + PCI bus)
Two PCIe mini card (PCIe bus)
One PCI slot (PCI bus)
Digital I/O
One 8-bit digital input/output connector; 4-bit input/4-bit output
through the ITE IT8718F super I/O
