NOVA-945GSE 5.25” SBC

Page 72

9 LVDSACLK+

10

LVDSACLK-

11 NC

12 NC

13 GND

14 GND

15 LVDSB1+ 16 LVDSB1-

17 LVDSB2+ 18 LVDSB2-

19 LVDSB3+ 20 LVDSB3-

21 LVDSBCLK+

22 LVDSBCLK-

23 NC

24 NC

25 GND

26 GND

27 LCDVCC 28 LCDVCC

29 LCDVCC 30 LCDVCC

Table 4-15: LVDS LCD Port Connector Pinouts

4.3.14 Parallel Port Connector

CN Label:

J3

CN Type:

26-pin header (2x13)

CN Location:

See

753H

Figure 4-16

CN Pinouts:

See

754H

Table 4-16

The 26-pin parallel port connector connects to a parallel port connector interface or some

other parallel port device such as a printer.
