NOVA-945GSE 5.25” SBC
Page 57
USB 2.0 connector
8-pin header USB2
USB 2.0 connector
8-pin header USB3
Table 4-1: Peripheral Interface Connectors
4.2.1 External Interface Panel Connectors
770H724H
Table 4-2 lists the rear panel connectors on the NOVA-945GSE. Detailed descriptions of
these connectors can be found in Section
771H725H
4.4 on page
772H726H
83.
Connector Type Label
Ethernet connector RJ-45 LAN1
Ethernet connector RJ-45 LAN2
Table 4-2: Rear Panel Connectors
4.3 Internal Peripheral Connectors
Internal peripheral connectors are found on the motherboard and are only accessible
when the motherboard is outside of the chassis. This section has complete descriptions of
all the internal, peripheral connectors on the NOVA-945GSE.
4.3.1 AT Power Connector
CN Label: J2
CN Type: 4-pin power connector (1x4)
CN Location: See
727H
Figure 4-3
CN Pinouts: See
728H
Table 4-3
The 4-pin +12V AT power connector is connected directly to an AT power supply.
