NOVA-945GSE 5.25” SBC
Page 56
Fan connector
3-pin wafer J1
Front panel connector
8-pin header F_PANEL1
IDE disk drive connectors (44-pin)
44-pin box header IDE1
Infrared interface (IrDA) connector
5-pin header IR1
Keyboard connector
6-pin wafer KB1
LVDS connector
30-pin crimp LVDS1
Parallel port connector
26-pin header J3
PCI-104 slot
120-pin socket J4
PC/104 slot
104-pin socket J6
PCIe Mini Card slot
PCIe Mini Slot MINI_PCIE1
PCIe Mini Card slot
PCIe Mini Slot MINI_PCIE2
SDVO connector
47-pin connector CN3
Serial ATA (SATA) drive connector
7-pin SATA SATA1
Serial ATA (SATA) drive connector
7-pin SATA SATA2
SATA power connector
2-pin wafer CN1
SATA power connector
2-pin wafer CN2
RS-232 serial port connector
10-pin header COM1
RS-232 serial port connector
10-pin header COM2
RS-232/422/485 serial port connector
10-pin header COM3
RS-232 serial port connector
10-pin header COM4
COM3 RS-422/485 connector 6-pin header JP2
TPM connector
20-pin header TPM1
TV Out connector
6-pin header TV1
USB 2.0 connector
8-pin header USB1
