IMBA-XQ354 Motherboard
Page 51
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
A40 SDONE B40 PERR
A41 SBO B41 +3.3 V
A42 GND B42 SERR
A43 PAR B43 +3.3 V
A44 AD15 B44 C/BE1
A45 +3.3 V B45 AD14
A46 AD13 B46 GND
A47 AD11 B47 AD12
A48 GND B48 AD10
A49 AD9 B49 GND
A52 C/BE0 B52 AD8
A53 +3.3 V B53 AD7
A54 AD6 B54 +3.3 V
A55 AD4 B55 AD5
A56 GND B56 AD3
A57 AD2 B57 GND
A68 AD0 B68 AD1
A59 +5 V B59 +5 V
A60 REQ64 B60 ACK64
A61 +5 V B61 +5 V
A62 +5 V B62 +5 V
Table 4-16: PCI Slot
4.2.14 SATA Drive Connectors
CN Label: SATA1, SATA2, SATA3, SATA4, SATA5 and SATA6
CN Type: SATA drive connectors
CN Location: See
892H892H
Figure 4-15
CN Pinouts: See
893H893H
Table 4-17
