IMBA-XQ354 Motherboard
Page 119
o +12.0 V
o FSB VTT
o +1.5 V
o +1.25 V
o VBAT
6.3.6 APM Configuration
Use the APM Configuration menu (
982H982H
BIOS Menu 10) to configure the drive connected to
SATA connector n.
BIOS Menu 10: AHCI Port n Configuration Menu
Î Restore on AC Power Loss [Last State]
Use the Restore on AC Power Loss BIOS option to specify what state the system
returns to if there is a sudden loss of power to the system.
Î
Power Off The system remains turned off
