6.3.5 Hardware Health Configuration
The Hardware Health Configuration menu (
980H980H
BIOS Menu 8 and
981H981H
BIOS Menu 9) shows the
operating temperature, fan speeds and system voltages.
BIOS Menu 8: Hardware Health Configuration
Î FAN Mode Setting [Full On Mode]
Use the FAN Mode Setting option to configure the fan mode options for the following
fans:
CPU
fan
System fan 1
System fan 2
The fan mode setting options are listed below.
Î
Full On Mode
D
EFAULT
Fan is on all the time
