Step 1:

Obtain the IP address of the client system.

Step 2:

On the remote management console, open a web browser.

Step 3:

If DHCP is enabled in the TCP/IP menu of the Intel® ME BIOS (Section 10

57H1057H

8.2,

Step 10), get the client system IP address in the MS DOS. Enter the client

system IP address and the port number in the web browser:

http://ip_address:16992 Example: http://192.168.1.7:16992 (

1058H1058H

Figure 8-11)

Or simply enter the defined host name: http://host_name:16992

Example: http://AMTsystem:16992

Figure 8-11: Intel® AMT Web Address

Step 4:

If a static IP address is defined for the Intel® AMT client system, enter the

defined client system IP address and the port number in the web browser.

Step 5:

A login window prompts (

1059H1059H

Figure 8-12).
