IMBA-XQ354 Motherboard
Page 33
Connector Type Label
PCIe x4 connectors PCIe x4 slot PCIEX4_1
PCIEX4_2
PCIEX4_3
PCIe x16 connector PCIe x16 slot PCIEX16_1
SATA connector 7-pin SATA SATA1
SATA2
SATA3
SATA4
SATA5
SATA6
SPDIF connector 5-pin header SPDIF1
Serial port connector 9-pin box header COM2
COM3
COM4
COM5
COM6
SPI flash connector 8-pin header JSPI1
Trusted Platform Module (TPM) 20-pin header TPM1
USB connector 10-pin header USB45
USB connector 10-pin header USB67
USB connector 10-pin header USB89
USB connector 10-pin header USB1011
Table 4-1: Peripheral Interface Connectors
