4.1 Peripheral Interface Connectors
Section 85
8H858H
4.1.2 shows peripheral interface connector locations. Section 85
9H859H
4.1.2 lists all
the peripheral interface connectors seen in Section 86
0H860H
4.1.2.
4.1.1 IMBA-XQ354 Layout
861H861H
Figure 4-1 shows the on-board peripheral connectors, rear panel peripheral connectors
and on-board jumpers.
Figure 4-1: Connector and Jumper Locations
4.1.2 Peripheral Interface Connectors
862H862H
Table 4-1 shows a list of the peripheral interface connectors on the IMBA-XQ354.
Detailed descriptions of these connectors can be found below.
Connector Type Label
ATX power connector, CPU 4-pin ATX CPU12 V1
ATX power connector, system 24-pin ATX ATX1
Audio connector 10-pin header FPAUDIO1
CD in connector 4-pin header CDIN1
Digital I/O connector 10-pin header DIO1
Fan connector, CPU 4-pin wafer CPU_FAN1
Fan connector, System 3-pin wafer SYS_FAN1
SYS_FAN2
Floppy disk connector 34-pin box header FDD1
Front panel connector 14-pin header F_PANEL1
Infrared connector 5-pin header IR1
PCI connectors PCI slot PCI1
PCI2
PCI3
