IMBA-XQ354 Motherboard

Page 90

Figure 5-18: PS/2 Keyboard/Mouse Connector

5.6.2 LAN

There are two external RJ-45 LAN connectors. The RJ-45 connectors enable connection

to an external network. To connect a LAN cable with an RJ-45 connector, please follow

the instructions below.

Step 1:

Locate the RJ-45 connectors. The locations of the USB connectors are shown

in Chapter 4.

Step 2:

Align the connectors. Align the RJ-45 connector on the LAN cable with one of

the RJ-45 connectors on the IMBA-XQ354. See

957H957H

Figure 5-19.
