The following voltages are monitored:
ƒ CPU Core
ƒ DDR2 1.8 V
ƒ 3.3 V
ƒ 5.0 V
ƒ 12.0 V
ƒ FSB VTT
ƒ 1.5 V
ƒ 1.25 V
ƒ VBAT
2.8.2 Power Consumption
855H855H
Table 2-1 shows the power consumption parameters for the IMBA-XQ354 with a
2.66 GHz E6850 Intel® Core™2 Duo CPU, 1333 MHz FSB and 8.0 GB of 800 MHz DDR2
RAM running 3DMark 2001.
Voltage Current
+ 3.3 V 2.96 A
+ 5.0 V 6.92 A
+ 5.0 VSB 1.61 A
+ 12.0 V 2.77 A
Table 2-1: Power Consumption
