IMB-Q354 uATX Motherboard
Page 60
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 MIC_L 2 GND
3 MIC_R 4 Audio Detect
5 LINE2-R 6 GND
7 Jack Detection 8 N/C
9 LINE2-L 10 GND
Table 4-10: Front Audio Connector Pinouts
4.2.9 Front Panel Connector
CN Label: F_PANEL1
CN Type: 14-pin header (2x7)
CN Location: See Figure 4-10
CN Pinouts: See Table 4-11
The front panel connector connects to external switches and indicators to monitor and
controls the motherboard. These indicators and switches include:
Power LED
Speaker
Power button
Reset
HDD LED
