4.1.2 Peripheral Interface Connectors
Table 4-1 shows a list of the peripheral interface connectors on the IMB-Q354. Detailed
descriptions of these connectors can be found below.
Connector Type Label
ATX power connector 24-pin ATX connector ATX1
CD in connector 4-pin header CD_IN1
Cooling fan connector, CPU 4-pin wafer CPU_FAN1
Cooling fan connector, System 3-pin wafer SYS_FAN1
CPU power connector 4-pin wafer CPU12V1
Digital input/output connector 10-pin header DIO1
DIMM socket 240-pin socket DIMM1
DIMM socket 240-pin socket DIMM2
DIMM socket 240-pin socket DIMM3
DIMM socket 240-pin socket DIMM4
Floppy drive connector 34-pin box header FDD1
Front audio connector 10-pin header FP_AUDIO1
Front panel connector 14-pin header F_PANEL1
Infrared (IrDA) connector 5-pin header IR1
PCI socket 120-pin slot PCI1
PCI socket 120-pin slot PCI2
PCIe x16 socket 164-pin slot PCIEX16
PCIe x4 socket 64-pin slot PCIEX4
PCIe power connector 4-pin wafer PCIE_12V1
