IMB-Q354 uATX Motherboard
Page 6
1.2.3 Technical Specifications
IMB-Q354 technical specifications are listed in Table 1-1. See Chapter 2 for details.
Specification IMB-Q354
Form Factor uATX
System CPU
LGA775 Intel® Core™2 Quad
LGA775 Intel® Core™2 Duo
LGA775 Intel® Celeron®
Front Side Bus (FSB) 800 MHz, 1066 MHz or 1333 MHz
System Chipset
Northbridge: Intel® Q35 Express Chipset
Southbridge: Intel® ICH9DO
Memory
Four 240-pin DDR2 DIMM sockets support 2.0 GB 667 MHz or
800 MHz DDR2 DIMMs
Super I/O ITE IT8712F Rev. I
Display Analog VGA display through external DB-15 connector
BIOS
AMI BIOS label
SPI EEPROM
4.0 MB
Audio RealTek ALC883 codec.
LAN
One Intel® 82566DM (PHY) and Intel® ICH9DO (MAC)
One PCIe x1 Intel® 82573L (MAC and PHY)
COM
Four RS-232 serial ports
Three by onboard pin-headers
One by external connector
USB2.0
Twelve USB 2.0 devices supported:
Eight by onboard pin-headers
