IMB-Q354 uATX Motherboard
Page 51
Connector Type Label
Audio connector Audio jack AUDIO_CV1
Ethernet and dual USB combo connector RJ-45 and two USB LAN1_USB01
Ethernet and dual USB combo connector RJ-45 and two USB LAN2_USB23
Mouse or keyboard connector PS/2 KB_MS1
Parallel port, serial port and VGA combo
connector
DB-25, DB-9 and
DB-15
3IN1_DSUB1
Table 4-2: Rear Panel Connectors
4.2 Internal Peripheral Connectors
Internal peripheral connectors are found on the motherboard and are only accessible
when the motherboard is outside of the chassis. This section has complete descriptions of
all the internal, peripheral connectors on the IMB-Q354.
4.2.1 ATX Power Connector
CN Label: ATX1
CN Type: 24-pin ATX (2x12)
CN Location: See Figure 4-2
CN Pinouts: See Table 4-3
The ATX connector is connected to an external ATX power supply. Power is provided to
the system, from the power supply through this connector.
