IMB-Q354 uATX Motherboard
Page 96
5.6.2 Motherboard Installation
To install the IMB-Q354 motherboard into the chassis please refer to the reference
material that came with the chassis.
5.7 Internal Peripheral Device Connections
5.7.1 Peripheral Device Cables
The cables listed in Table 5-5 are shipped with the IMB-Q354.
Quantity Type
1 Dual RS-232 cable
6 SATA drive cables
3 SATA drive power cables
1 USB cable
Table 5-5: IEI Provided Cables
Separately purchased optional IEI items that can be installed are listed below:
TPM Module
For more details about the items listed above, please refer to Chapter 3. Installation of the
accessories listed above are described in detail below.
5.7.2 Dual RS-232 Cable Connection
The dual RS-232 cable consists of two connectors attached to two independent cables.
Each cable is then attached to a D-sub 9 male connector that is mounted onto a bracket.
To install the dual RS-232 cable, please follow the steps below.
Step 1: Locate the connectors. The locations of the RS-232 connectors are shown in
Chapter 3.
Step 2: Insert the cable connectors. Insert one connector into each serial port box
