Teledyne LeCroy
Voyager USB 3.0 Exerciser Generation Script Language Reference Manual
55
Pipe Commands
The following are the defined Pipe Command types (and the corresponding constants defined in
PipeCommands.ginc):
Pipe Command
Value
Description
PIPE_CMD_READ_DATA
0x01
IN transfer (bulk or data stage of control) for Host
emulation, responding to an OUT transfer for
Device emulation
PIPE_CMD_WRITE_DATA
0x02
OUT transfer (bulk or setup/data stage of control)
for Host emulation, responding to an IN transfer for
Device emulation
PIPE_CMD_GET_STATUS
0x03
Device emulation, responding to the Status stage
of a control transfer
PIPE_CMD_SEND_STATUS 0x04
Host emulation, sending the Status stage of a
control transfer
PIPE_CMD_SEND_PING
0x06
Sending the Ping to a device for Host emulation,
or sending a Ping response for Device emulation
Pipe Type
The following are the defined Pipe Type values (and the corresponding constants defined in
PipeCommands.ginc):
Pipe Type
Value
Description
PIPE_TYPE_CONTROL
0
Control pipe, all directions
PIPE_TYPE_BULK
1
Bulk pipe
PIPE_TYPE_INTERRUPT
2
Interrupt pipe (for future extension)
PIPE_TYPE_ISO
3
Isochronous pipe (for future extension)
