Teledyne LeCroy Voyager USB 3.0 Exerciser Generation Script Language Reference Manual
141
12 Appendix B - Raw Register Settings
The following registers can be set using the SetRegister function:
SetRegister(, )
Register Name Register
Address Comment
SKP_TIMER 0x0014 See Below
TRAINER_RESET 0x0030 0x0 : Remove PHY layer (Including LTSSM) from reset mode
0x010000000 : Keep PHY layer (Including LTSSM) in reset mode
0x4 : This will direct LTSSM from Polling to HotReset, the first time
LTSSM passes through Polling state.
0x01800000 : Phy layer in reset mode, as well as trainer function
PM_ACCEPT_MODE 0x0064 See Below
CORRUPT_LC 0x0114 See Below
CORRUPT_LMP 0x0118 See Below
CORRUPT_SHP_FRAMING 0x0124 See Below
CORRUPT_SDP_FRAMING 0x0128 See Below
CORRUPT_END_FRAMIN
G 0x012C See Below
CORRUPT_SLC_FRAMING 0x013C See Below
DELAY_LAU 0x015C See Below
Insert K-Sym Error (LC
and HP) 0x0160 See Below
LTSSM_ SETTING 0x0200 See Below
LTSSM_U3EXIT_CONTROL 0x0214 See Below
LTSSM_HOT_RESET_TIME 0x0218 See Below
