Voyager USB 3.0 Exerciser Generation Script Language Reference Manual
155
LTSSM_SETTING register is set. The time is specified with 8ns granularity.
MSB
LSB
Reserved
HotReset Time
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
HotReset Time
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Bit Location
Register Description
Attributes
27:0
HotReset Time
Time of staying in HotReset.Active when the HotReset fast
exit is disabled (Refer to LTSSM_SETTING). Value
specified should be less than 12 ms (= 0x16E360) and
preferred to be more than 0x20 (required time for sending 8
TS2s).
Default value is 0x96, equal to 1.2 us.
RW
31:28
Reserved, filled by 0
RO
12.1.14
LTSSM_RXDETECT_CONTROL
(Offset in the Register Area: 0x021C)
This register contains RxDetect controlled behavior settings. LTSSM can repeat
RxDetect.ActiveRxDetect.Quiet loop for requested times even if far-end receiver termination
detected. Also, the delay time in RxDetect.Quiet can be set through this register. It will affect if
corresponding bit (RxDET) in
