Teledyne LeCroy Voyager USB 3.0 Exerciser Generation Script Language Reference Manual
103
10.7 Using Structure Variables to Assign Field Values
You can use structure variables in field assignments. Also see the Using Multipliers to Assign
Field Values section.
Examples
Main
{
# Use structure variables to assign field values.
# Declare a 'structure' instance based on the template S1.
$S = S1
# Declare a 'structure' instance based on the template S2
# and change the default value for the S16 field.
$W = S2 { S16 = 2 }
Send TX_PACKET
{
Data = $S
# Data field contains the payload of structure S .
}
Send TX_PACKET
{
# Example of concatenation of structures.
# Data field contains combined payload of structures
S and W
Data = $S + $W
}
}
