Bit Location Register Description
Pending count = 0 => interval = 353
Pending count = 1 => interval = 707
Pending count = 2 => interval = 1061
Pending count = 3 => interval = 1215
15:12 Reserved, filled by 0
31:16 Interval
User defined interval time in terms of 8ns units. HW will
meet it with the best possible accuracy if AUTO bit is not
set.
12.1.2 PM_ACCEPT_MODE
(Offset in the Register Area: 0x0064)
This register controls the behavior of the device in response to Power Management states entry request
(LGO_Un).
MSB LSB
Reserved
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved DRO
P
Auto AU3 AU2 AU1
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Bit Location Register Description Attributes
0 AU1
0: Reject the request of entering U1 by sending LXU,
1: Accept the request of entering U1 by sending LAU RW
1 AU2
0: Reject the request of entering U2 by sending LXU,
1: Accept the request of entering U2 by sending LAU RW
2 AU3
0: Reject the request of entering U3 by sending LXU,
1: Accept the request of entering U3 by sending LAU* RW
3 AUTO
0: Reply to the LGO_Un according to the bits 0 to 2.
1: Reply to the LGO_Un based on the configured value
through LMPs. RW
4 LAU Drop
0: Normal
1: Drop any LAU. RW
31:4 Reserved, filled by 0 RO
* It seems problematic because according to spec, LGO_U3 shall be replied just by a LAU.
12.1.3 CORRUPT_LC
(Offset in the Register Area: 0x0114)
This command forces the link layer to send LCs with wrong CRC-5. It will effect on any LC outgoing from
the link layer until the command is stopped automatically or manually. All the other details are just similar
to Error! Reference source not found..
