Teledyne LeCroy
Voyager USB 3.0 Exerciser Generation Script Language Reference Manual
10
PortCfgAck
Specifies whether the Exerciser responds to Port Config LMPs or not.
Example: Set PortCfgAck = 0
Possible values are:
0 # Do not respond to PortConfig LMPs.
1 # Automatically respond to PortConfig LMPs.
Default value: 1
Applicable Mode: HOST, DEVICE
LTSSMSettings
LTSSM Setting flags.
Example: Set LTSSMSettings = CUSTOM_TS1
Possible values are any combinations of the following flags:
0 # AUTO.
DISABLE_LFPS = 0x1 # Disable Polling.LFPS detection.
CUSTOM_TSEQ = 0x2 # Send specified number of TSEQ
(TSEQNumber setting), then go to the next state.
CUSTOM_TS1 = 0x4 # Send TS1 for specified period of time
(TS1Time setting), then go to the next state.
CUSTOM_TS2 = 0x8 # Send TS2 for specified period of time
(TS2Time setting), then go to the next state.
DISABLE_IDLE = 0x10 # Disable Logical Idle handshake, so LTSSM
jumps over relevant sub-state.
Default value: 0 (auto)
Applicable Mode: DEVICE, HOST
TSEQNumber
Specifies number of TSEQ Ordered Sets to be sent in Polling.RxEQ
sub-state. Applies only if CUSTOM_TSEQ bit is set in the
LTSSMSettings setting.
Example: Set TSEQNumber = 64000
Possible values are any values from 0 to 65535 (0xFFFF).
Default value: 65535
Applicable Mode: DEVICE, HOST
TS1Time
Specifies the time in nanoseconds to stay in the Polling.Active or
Recovery.Active sub-states, regardless of received pattern. Applies
only if bit CUSTOM_TS1 of the LTSSMSettings is set.
Example: Set TS1Time = 2000
Possible values are from 0 to 5000000 (5 ms). It is recommended not
to use values < 267 ns (required time for sending 8 TS1s)
Default value: 1000 (1 us)
Applicable Mode: DEVICE, HOST
TS2Time
Specifies the time to stay in the Polling.Active or Recovery.Active
sub-states, regardless of received pattern. Applies only if bit
CUSTOM_TS2 of the LTSSMSettings is set.
Example: Set TS2Time = 1000
Possible values are from 0 to 5000000 (5 ms). It is recommended not
to use values < 267 ns (required time for sending 8 TS2s)
Default value: 1000 (1 us)
Applicable Mode: DEVICE, HOST
