Turning on cursors, Cursor types, Horizontal (time) – Teledyne LeCroy WaveSurfer MXs-B Getting Started Manual User Manual
Page 51: Vertical (amplitude)

Getting Started Manual
922172-00 Rev A
43
Turning On Cursors
Cursors automatically turn on when either knob is rotated.
Or, you can press the T
YPE
button to turn cursors ON, and
then toggle through the various cursor types.
Cursor Types
Horizontal (Time)
Horizontal (Time) cursors are moved left and right along
the waveform. Place them at a desired location along
the time axis to read the signal’s time and amplitude
information at the selected location.
Vertical (Amplitude)
Vertical cursors are lines that you move up and
down on the grid to measure the amplitude of a
signal.
