WaveSurfer MXs-B Oscilloscopes
94
922172-00 Rev A
Options
Use this dialog to add or remove software options. For information about
software options, contact your local Teledyne LeCroy Sales and Service
office, or visit our Web site at http://teledynelecroy.com/options.
Options that you purchase, such as FlexRaybus TD, add performance to
your instrument. This added performance is seen in the new math
functions you can choose from when setting up the Math trace.
Service
This button provides access to service dialogs, which are for the sole use of
Teledyne LeCroy service personnel. A security code is required to gain
access.
Show Windows Desktop
Touching the Show Windows Desktop button in the main Utilities dialog
minimizes the instrument application to reveal the underlying desktop.
Maximize the application, by touching the shortcut icon:
Touch-Screen Calibration
Touching the Touch-Screen Calibration button starts the calibration
procedure. During the procedure, you are prompted to touch the center of
a small cross in 5 key locations on the touch-screen. Be sure to use a stylus
