Getting Started Manual
922172-00 Rev A 97
If you chose MAPI, touch inside the Originator Address (From:) data entry
field and use the pop-up keyboard to type in the instrument's e-mail
address. Then touch inside the Default Recipient Address (To:) data entry
field and use the pop-up keyboard to enter the recipient's e-mail address.
If you chose SMTP, touch inside the SMTP Server data entry field and use
the pop-up keyboard to enter the name of your server. Touch inside the
Originator Address (From:) data entry field and use the pop-up keyboard
to type in the instrument's e-mail address. Then touch inside the Default
Recipient Address (To:) data entry field and use the pop-up keyboard to
enter the recipient's e-mail address.
You can send a test e-mail text message by touching the Send Test Mail
button. The test message reads "Test mail from [name of oscilloscope's e-
mail address]."
Acquisition Status
For each general category of oscilloscope operation, you can view a
summary of your setups. These dialogs are not accessible through the
Utilities dialog, but are instead accessed from the menu bar drop-down
menus. The categories are as follows:

Vertical - select Channels Status . . . from drop-down menu

Timebase - select Acquisition Status . . . from drop-down menu

Trigger - select Acquisition Status . . . from drop-down menu

Math - select Math Status . . . from drop-down menu
In addition to these dialogs, summaries are also provided for XY setups,
memory (M1-M4) setups, and time stamps for sequence mode sampling.
Remote Control Operation
Refer to the Remote Control Manual available at teledynelecroy.com for
more information.
You can fully control your instrument remotely. The only actions for which
you must use the front panel controls are the powering up of the
oscilloscope and the setting of remote control addresses.
