57
6. Inspection/Maintenance
6.4.5 Writing the Flash ROM
(1) Following an absolute reset of the rotational axis and vertical axis, the following screen opens when the
absolute reset window is closed. Click the “Yes” button.
x Clicking “Yes” writes the information in the flash ROM.
x The flash ROM must also be written when home position automatic update has been performed for arm 1
or 2.
(2) When the writing of flash ROM is complete, the following screen is displayed. Click the “Yes” button.
x The controller is restarted and the software is reset.
