13. Inspection/Maintenance
Arm 1
Positioning mark
label for arm 1
Positioning
mark label
for arm 2
Arm 2
Inse
rtio
n dep
th
Approx. 60 mm
Inse
rtio
n dep
th
A
pprox. 20 mm
z Always press the emergency-stop switch before setting an adjustment jig. Failure to do so may cause the
robot to malfunction and result in a serious accident.
Warning
