7
7. Installation
Notes on Installation
[Stainless sheet]
The stainless sheet is designed very thin (thickness: 0.1 mm) in order to ensure flexibility. Therefore,
the stainless sheet is easily dented or scratched. Once dented or scratched, the stainless sheet may
break during use.
When installing the stainless sheet, pay attention to the following points. Also, be careful not to let a
tool or work part drop onto the actuator to dent the exterior of the actuator.
Do not press the sheet directly with hands.
Do not generate powder dust or iron powder around the stainless sheet.
If dust/powder has generated, thoroughly remove attached dust/powder from the stainless sheet after the
operation.
If the actuator is operated with the stainless sheet carrying foreign particles, the particles may enter the
slider and damage the sheet or cause the sheet to deform, lift or present other problems.
Also, magnets are attached to the side covers to keep the stainless sheet in position. Since these
magnets attract metal debris, iron powder and other metal objects, due attention must be paid to the
surrounding environment.
Do not press the sheet directly with hands.
[Slider cover]
Do not apply force on the slider cover. It may cause interference and other damages.
Slider cover
