1. Checking the Product
13
[When high–output setting is ineffective]
Strokes and maximum speed limits (Unit: mm/s)
Stroke [mm]
Size
Motor
Type
Lead
[mm]
Horizontal /
Vertical
50 100 150 200 250 300 350 400 450 500
Horizontal 125
3
Vertical 125
Horizontal 250
6
Vertical 250
Horizontal 500
12
Vertical 500
Horizontal 640
RA5C 42P
20
Vertical 640
Horizontal 140
4
Vertical 140
Horizontal 210
8
Vertical 210
Horizontal 420
16
Vertical 420
Horizontal 600
RA6C 56P
24
Vertical 400
Horizontal 125
3
Vertical 125
Horizontal 250
6
Vertical 250
Horizontal 500
12
Vertical 500
Horizontal 640
RA5R 42P
20
Vertical 640
Horizontal 140
4
Vertical 140
Horizontal 210
8
Vertical 210
Horizontal 420
16
Vertical 420
Horizontal 600
RA6R 56P
24
Vertical 400
