1. Checking the Product
10
1. Specifications Check
1.1 Checking the Product
The standard configuration of this product is comprised of the following parts.
See the component list for the details of the enclosed components. If you find any fault or missing parts, contact
your local IAI distributor.
1.1.1 Parts
No. Name Model number Quantity Remarks
1 Actuator
Refer to “How to Read the Model
Nameplate” and “How to Read the
Model Number.”
1
Accessories
2 Motor • encoder cables (Note1) 1
3 Homing stickers 1
4 Nut 1 Refer to list below
5 First Step Guide 1
6 Operation Manual (CD/DVD) 1
7 Safety Guide 1
Note1 The motor • encoder cables supplied vary depending on the controller used.
[Refer to 1.4, “Motor • Encoder Cables.”]
(List of Included Nut Type)
Model No.
Nut
(M10u1.25)
Nut
(M14u1.5)
RCP4–RA5C, RA5R 1
RCP4–RA6C, RA6R 1
1.1.2 Related Operation Manuals for the Each Controller Supported by this Product
Shown below is a list of the instruction manuals for the controllers related to this product which is recorded in
Instruction Manual (DVD).
No. Name Control No.
1 Operation Manual for PCON㵨CA Controller ME0289
2 Operation Manual for RC PC Software RCM㵨101㵨MW/RCM㵨101㵨USB ME0155
3 Operation Manual for CON㵨PTA/PDA/PGA ME0295
1.1.3 How to Read the Model Nameplate
Model
Serial number
MODEL RCP4-RA5C-I-42P-3-50-P3-P-B
SERIAL No.000090266 MADE IN JAPAN
