4. Maintenance Inspection
44
11) Affix the belt to the belt holder.
Align the belt teeth on the belt holder with the drive belt, and tighten the bolts (M3 × 6).
Tightening torque: 154N cm (15.7kgf cm)
12) Move the slider to a position where it aligns with the mounting holes in the belt holder, and tighten
the bolts (BA6: M3 × 6 / BA7: M3 × 12).
Tightening torque: 83N cm (8.5kgf cm)
13) Affix the belt-cover support (resin) using the bolts (M3 Ч 6).
