92
9.5 Hook Block Parts
Figure No. Part Name
Parts
Per
Hoist
RHN15U
55 RHN15U Bottom Hook Block 1 RHN0335
1 Side cheek 2 RHN0336
4 Protection hood 4 RHN0337
6 Rope pulley 2 RHN0327
9 Grooved ball bearing 4 9000612
10 Axle 1 RHN0338
12 Adjusting washer 4 9098807
14 Joining element 2 RHN0340
15 Joining element 2 RHN0341
20 Pin 2 RHN0342
22 Locking ring 2 9047193
32 Traverse 1 RHN0346
33 Axial bearing 1 9001227
34 Guard plate 1 RHN0347
30 Load hook assembly 1 RHN0345
31 Load hook attachment 1 -
35 Nut 1 -
37 Locking plate 1 RHN0350
38 Hexagon head cap screw 2 9093347
39 Spring washer 2 9012712
40 Safety catch 1 RHN0353
50 Capacity Plate 2 RHN0354
51 Blind rivet 4 RHN0050
53 Name plate 2 RHN0620
54 Blind rivet 8 RHN0050
