108
9.8 Trolley Motor & Gear Box Assembly Parts
Figure No. Part Name
Parts
Per
Hoist
RHN02 RHN03 RHN05 RHN08 RHN10 RHN15
50
TROLLEY MOTOR & GEAR BOX ASSEMBLY 1 ,
DUAL SPEED – 80/20 fpm
1V
1
RHN0725 RHN0728 RHN0731
2V RHN0726 RHN0729 RHN0732
4V RHN0425 RHN0426 RHN0427
5V RHN0727 RHN0730 RHN0733
7 Brake kit 2
1V
2V
4V
1
RHN0388 RHN0403 RHN0407
5V RHN0389 RHN0404 RHN0408
1 Brake rotor kit 3 1 RHN0387
12 Nut 1 RHN0390 RHN0409
14 Fan wheel 1 RHN0391 RHN0410
16 Fan cover kit 4 1 RHN0392 RHN0411
21 Bearing kit (Inc. 3-5,8,9) 1 RHN0393 RHN0412
23 Bearing kit 5 1 RHN0394 RHN0413
28 Terminal box 1 RHN0395
29 Terminal box lid 1 RHN0396
30 Rectifier
1V
1
RHN0397
2V
4V
5V
RHN0398
31 Plug connector 1 RHN0399
32 Round sealing ring 1 RHN0400
34 Socket head cap screw 4 9091250 9091294
35 Lock washer 4 9012709 9012712
38 Sealing ring 1 RHN401 RHN0414
1 Lubricant included
2 Brake kit includes brake rotor kit, brake, snap ring, and key
3 Brake rotor kit includes brake rotor, screws, and o-rings
4 Fan cover kit includes fan cover, screws, and lock washers
5 Bearing kit includes bearing and shaft seal
