9.6 Terminal Box Parts
Component
No.
Part Name
Parts
Per
Hoist
RHN15U
208, 230V 460, 575V
A275
RPU Overload Device (SLE21)
1
RHN0500 RHN0500
RPU Overload Device (SLE22) RHN0575 RHN0575
F41-F43
Fuse Holder 3 RHN0501 RHN0501
Fuse Link 3 RHN0529 RHN0529
F101-F102 Fuse Holder 2 RHN0501 RHN0501
Fuse Link 2 RHN0541 RHN0518
G21 Rectifier 1 RHN0542 RHN0504
K10 Contactor , Mainline 1 RHN0543 RHN0519
K23-K24
Contactor , Hoist Directional 2 RHN0543 RHN0519
Auxiliary Contact Block 1 RHN0505 RHN0505
K25 Contactor , Hoist Speed 1 RHN0537 RHN0520
K29 Contactor, Hoist Brake 1 RHN0528 RHN0528
K41-K42 Contactor , Trolley Directional
1 RHN0509 RHN0509
K45 Contactor , Trolley Speed 1 RHN0510 RHN0510
Q29 Circuit Breaker 1 RHN0544 RHN0522
Auxiliary Contact Block 1 RHN0521 RHN0521
S220 Gear-Type Limit Switch 1 RHN0511 RHN0511
T100 Transformer 1 RHN0545
RHN0523 (*460V)
RHN0524 (*575V)
N/A Transformer Fuse 1 9006278 9006202
X16
PE -Terminal 1 RHN0530 RHN0530
Terminal 3 RHN0531 RHN0531
PE -Terminal 1 RHN0525 RHN0527
Terminal 2* RHN0533 (*Qty=6) RHN0515
PE -Terminal 5 RHN0516 RHN0516
Terminal 20 RHN0517 RHN0517
