Harrington Hoists and Cranes RHN - Rhino Wire Rope Hoist - Manual (Page 51)

51
Table 5-11 - Travel Motor Brake
Hoist
Capacity
Code
Motor Type
Motor Speed
(fpm)
S
min.
in. (mm)
S
max.
in. (mm)
t
in. (mm)
Screw
Torque
ft-lbs (Nm)
RHN02U Dual speed 80/20 .008 (0.2) .079 (2.0) .22 (5.7) 2.2 (3)
RHN03U Dual speed 80/20 .008 (0.2) .079 (2.0) .22 (5.7) 2.2 (3)
RHN05U Dual speed 80/20 .008 (0.2) .079 (2.0) .22 (5.7) 2.2 (3)
RHN08U Dual speed 80/20 .008 (0.2) .063 (1.6) .24 (6.1) 2.2 (3)
RHN10U Dual speed 80/20 .008 (0.2) .063 (1.6) .24 (6.1) 2.2 (3)
RHN15U Dual speed 80/20 .012 (0.3) .079 (2.0) .35 (8.8) 7.4 (10)
