9.2 Gearing Parts
Figure
No.
Part Name
Parts
Per
Hoist
RHN02
RHN03
RHN05
RHN08
RHN10
10
2-10 Ton Gear Assembly, Standard
1
RHN0304
RHN0306
RHN0308
1 Cover
1
RHN0001
RHN0085
RHN0146
2 Seal
1
RHN0002
RHN0086
RHN0147
3 Socket head cap screw
8
9691201
4 Lock washer
8
9012709
5 End cap
1
RHN0003
RHN0045
RHN0132
6 End cap
1
RHN0003
RHN0088
RHN0149
7 Shaft seal
1
RHN0004
RHN0089
RHN0150
8 Snap Ring, external
1
9047120
9047148
9047175
9 Supporting ring
1
9098801
9098803
9098805
